Grado has combined newly developed coil winding techniques with decades-old disciplines. A new two-step shielding process brings not only exact unison between the four coils but an unobstructed path for a cleaner signal. The music is allowed to travel undistorted through the coils, greatly reducing mechanical noise. There is an extreme clarity over the full frequency range, with absolutely no stridency or shrillness. Precisely hand tipped with a diamond, a great amount of care go into each cartridge we build.

Body: American Maple Wood

Cantilever: Aluminum/Elliptical Diamond

High 4.0mV @5 CMV (45)/Low 1.0mV @5 CMV (45)

High Output 55mH/Low Output 6mH

High Output 660 ohms/Low Output 70 ohms

Input Load: 10k-47k ohms

Cartridge Weight: 8.3 grams

Tracking Force: 1.6-1.9 grams

Compliance: 20μm/mN

Channel Separation: Average 30dB - 10-30kHz

Controlled Frequency Response: 10-60kHz
