The Audiolab 9000Q is a preamplifier that embodies the audio excellence of the flagship 9000 series. This refined preamplifier embodies a symphony of innovation and craftsmanship, featuring functional enhancements that elevate your listening journey. With its tone controls and fully balanced signal paths, the 9000Q empowers you to explore your music with unparalleled versatility and precision.

Audiolab 9000Q Digital / Analogue Preamplifier:
Type: Preamplifier
Technology: ES9038Pro 32-bit DAC, MQA Full decoder, Dedicated Current-Feedback Headphone Amp, Dedicated High Performance Low Noise MM Phono stage
Display: 4.3” 800 x 480 IPS LCD

Inputs:
Analog Inputs: 3 x Analogue (RCA), 1 x XLR, 1 x Phono (MM)
Digital Inputs: 2 x SPDIF (Coax), 2 x SPDIF (Optical), 1 x PC USB (USB B), 1 x Bluetooth (aptX/aptX HD/LDAC)

Outputs:
Outputs: 2 x RCA, 1 x XLR, 1 x Headphone, 2 x 12V Trigger

Sampling Frequency:
Optical/Coaxial: 44.1-192kHz
PC USB: 44.1kHz-768kHz (PCM) / DSD64, DSD128, DSD256, DSD512

Preamp / DAC Performance:
D to A Converter: ES9038Pro
Input Sensitivity: 1Vrms (Line, Volume = 0dB), 2Vrms (XLR, Volume = 0dB), 4.5mV (Phono MM, Volume = 0dB)
Total Harmonic Distortion (THD): < 0.001% (1KHz @ 0dBFS)
Frequency Response: 20Hz - 20kHz (+/-0.1dB)
Output Impedance: 120 ohm
Max. Sampling Frequency: Optical/Coaxial: 192KHz; PC USB: PCM768kHz, DSD512
Signal-to-noise Ratio (S/N): > 113dB (A-weighted, RCA); > 117dB (A-weighted, XLR Direct)

Headphone Amplifier:
Total Harmonic Distortion (THD): < 0.01% (1kHz, 50mW)
Output Impedance: 2.35 ohm
Load Impedance: 20-600 ohm

General:
Standby Power Consumption: <0.5W
Net Weight: 6.2kg
Gross Weight: 8kg
Dimensions (W x H x D): 444 x 90 x 328 mm
Finish: Silver / Black
Power Requirements: 220-240V - 50/60Hz or 100-120V - 50/60Hz (depending on region)

Standard Accessories:
Power Cord, Remote Control, User Manual, Antennas
