Balanced audio connections are usually known from the professional sector like recording studios or live concerts. It is very important to have a stable & interference free connection, as these signals will be highly amplified. The same applies to the connection from your turntable to the phono preamplifier. The big advantage of a balanced connection is its ability to remove picked up noise and interferences. And best of all, cartridges by nature are already balanced signal transducers! With True Balanced your are simply using everything, literally everything, that your cartridge is picking up from the record groove. You are not throwing away half of the usable signal, like is done in typical single-ended RCA phono connections.
The X2 B comes with mini XRL and RCA outputs and with our standard semi-balanced Connect it Phono E RCA cable. By upgrading it to our fully balanced mini XLR to mini XLR version (available separately) and using a balanced phono stage, like our Phono Box S3 B or DS3 B, you are fully set-up for the True Balanced experience. This leads to increased dynamics, less noise and improved signal to noise ratios. You can imagine it, like hearing parts of your music that literally were not there before.
True Balanced
Unleash the full power
Simply upgrade your X1 B to a MC cartridge, connect it with one of our new True Balanced Phono Cables to your phono preamp and benefit from an interference-free signal with increased dynamics & lower noise level.
Mini XLR Output
One cable connects it all
We offer a wide range of balanced phono cables with different connectors to fit all our phono preamps. If you want to use your X1 B with a Phono Box S3 B you need a „Connect it Phono Mini XLR / Mini XLR“.
Balanced Preamps
A perfect match!
Pair your X1 B with one of our new balanced Phono Boxes and benefit from a fully balanced signal transmission to your phonp preamplifier. Check out our new Phono Box S3 B & DS3 B for further information.
9'' Carbon-Aluminium Tonearm
Compared with its little brother the X1 B, the tonearm is longer - 9“ in length - and the tube has a wider diameter. The carbon/aluminium sandwhich construction results in better internal damping. The increased mass makes the tonearm an excellent fit for low compliance MC cartridges.
Motor suspension
A good motor by itself, is already very quiet. To get the best performance out of it, we have improved the motor suspension. The X2 B‘s motor chassis is carefully balanced and suspended on a precision tuned TPE belt - this way the motor chassis is effectively decoupled from the main plinth for optimal performance.
Real high-end features.
Azimuth & VTA
Fully adjustable
The X1 comes with fully adjustable Azimuth & VTA. It offers you the possibility to modify your X1 as you want it.
Metal Feet
Damped & height adjustable
The three height adjustable damped aluminium feet guarantee the perfect stand & massively reduce risk of acoustical feedback.
2 kg Platter
Resonance free acryl
The perfect platform to place your precious vinyl records, guaranteeing absolute reliability in its performance and sonic character.
33/45/78 RPM
High precision motor control
A sophisticated DC/AC generator board generates clean and stable power to drive the motor. Easily change speed with the push of only a single button.
| Speed |
33, 45, 78 (electronic speed change) |
| Principle |
belt drive |
| Speed variance |
33: 0.25% 45: 0.20% |
| Wow & flutter |
33: 0.12% 45: 0.10% |
| Signal to noise |
70 dB |
| Platter |
30mm thick, 2 kg heavy acryl |
| Main bearing |
stainless steel/brass |
| Tonearm |
9” carbon/aluminium sandwich |
| Effective arm length |
230 mm |
| Overhang |
18 mm |
| Effective tonearm mass |
13,5g |
| Tracking force range |
0 - 30mN |
| Included accessories |
15volts DC /0,8A power supply, Dust cover, Connect it E Phono cable, feltmat |
| Power consumption |
4,5 watts max / 0.3 watt standby |
| Dimensions |
460 x 150 x 340 mm (WxHxD) |
| Weight |
10 kg |
