Chord ANNI Desktop Integrated Amplifier:
Type: Solid-State Desktop Integrated Amplifier
Amplifier Topology: Class AB
Power Output:
Rated Output Power: 20W per channel into 8Ω
Distortion & Performance:
Total Harmonic Distortion (THD): <0.05% (20Hz - 20kHz)
Frequency Response: 3Hz - 50kHz (+0/-3dB)
Signal-to-Noise Ratio (S/N): >100dB (A-Weighted)
Crosstalk: >75dB at 1kHz
Input Section:
Analog Inputs: 1 × 3.5mm Stereo Mini-Jack, 1 × RCA (Line Level)
Input Impedance: 10 kΩ
Output Section:
Speaker Outputs: 2 × Binding Posts
Headphone Output: 1 × 3.5mm Jack (on front panel)
Headphone Output Power: Up to 1W into 32Ω
General Specifications:
Power Supply: 24V DC External Power Adapter (Included)
Dimensions (W×D×H): 160mm × 160mm × 33mm
Weight: 0.95 kg
Finish: Anodized Aluminum (Silver or Black)
Included Accessories:
Standard Accessories: Power Adapter, 3.5mm to RCA Cable, Rubber Feet
Additional Features:
Compact Desktop Design: Ultra-small footprint
Headphone Amp: Integrated high-quality headphone amplifier
No Internal DAC: Analog-only input section (requires external source or DAC)
