The new REVO DAC-2 represents one world’s best expression in the realization of Digital-to-Analog converters. Using the newly developed in house A-DAC.

With extremely low noise floors and a penchant for a more analog sound, the REVO line is sure to readjust expectations of digital playback quality.  Norma's desire for a more analog sound can be found in the heart of these units with the A-DAC proprietary conversion technology.  Why A-DAC?  Because A represents their pursuit of Analog. With proprietary I-V Conversion and a fully discrete analog section, the A-DAC is an advancement years in the making.

In a historical moment when we witness the proliferation of DACs for “computer music”, exclusively designed around the parameters of the so-called technical modernity and cost reduction to the detriment of the potential sound performance of high resolution devices, NORMA proposes a “universal machine” which is highly sophisticated in all the aspects relevant to sound output. You can finally truly appreciate the actual quality of high resolution files, without the limitations imposed by inadequate implementation.
NORMA is pleased to present the new REVO DAC-1 Digital Source. It is an extremely interesting product, both for its outstanding technical content and for its noticeable versatility, obviously combined with the rigor of NORMA musical tradition.
All of this at a very interesting price, considering the technical features.

Norma Audio REVO DAC-2 Reference DAC:
Type: Reference DAC (Optional board for REVO SC-2 preamplifier)

Inputs (Connections):
IN1 : USB, 2.0 High Speed
IN2 : SPDIF RCA, 75Ω
IN3 : AES/EBU XLR, 110Ω
IN4 : TOSLINK OPTICAL (up to 96 KHz, 192.0 KHz may be achieved but not guaranteed)
IN5 : SPDIF RCA, 75Ω (configurable as SPDIF Output for CD mechanism)
Supported Resolution: Up to 24 Bit / 192 KHz

Outputs:
Analog Outputs: Via host preamplifier's outputs (RCA & XLR)
Digital Output (Optional): IN5 can be set as SPDIF Output

Digital Processing:
Sampling Frequencies: 44.1KHz, 88.2KHz, 176.4KHz, 48.0KHz, 96.0KHz, 192.0KHz
UpSampler Frequencies: 44.1KHz, 88.2KHz, 176.4KHz, 48.0KHz, 96.0KHz, 192.0KHz, AUTO MODE
UpSampler Chip: Based on TI SRC4392
Oversampling: DF 1706 8 x Digital Filter
Oversampling Filter: User selectable Sharp & Slow Roll-off filter response
Digital Filter: Slow & Sharp mode, based on TI DF1706
De-emphasis: 44.1KHz, 48.0KHz, auto and manual mode
D/A Converter: Norma A-DAC, 24 Bit D/A converter

Clock & Performance:
Clock System: Two separate local clock oscillators for 22MHz / 24 MHz (44.1 / 48KHz families)
Clock Performance: +/- 2ppm typ. at 25°, +/- 10ppm at 60°
Clock Source Selection: Can use local oscillator or clock from input signal

Analog Stage:
I/V Conversion: Proprietary topology with discrete component
Output Stage: Proprietary topology with discrete component, high linearity & low noise
Configuration: Solid state
Analogue Output Filter: 0.0 to 180 kHz +/- 3 dB
Analogue Stage Frequency Response: 0.0 to 2MHz +/- 3 dB
Topology: Extreme low noise, high resolution, high speed, wide band (>2 MHz)

Control & Features:
Control: Full remote controlled by REVO SC-2 preamplifier
Customization: Possibility to customize for each digital input all parameters, including oversampling value
