NAD Integrated Amplifier C 328

Art and Sound

For 45 years, NAD Electronics has introduced aspiring audiophiles to the vast world of hi-fi. From our flagship Masters Series, to our budget-friendly Classic Series, NAD has a component for everyone. Following in the footsteps of some of NAD’s greatest units, the NAD C 328 delivers the most fundamental of features, while firmly adhering to NAD’s unwavering commitment to exquisite sound. The C 328 can wirelessly connect to any smartphone, tablet, or Bluetooth®-enabled device within range, to give you a seamless listening experience. Featuring a MM phono input, the C 328 breathes new life into vinyl LPs, thanks in part to NAD’s innovative Hybrid Digital™ amp technology. The C 328 also features a headphone amplifier, letting you connect your favourite headphones and settle back into your own world of detailed sound. Although more modest in comparison to other Classic Series amplifiers, the C 328 will fit perfectly into your existing system and bring you the musical nirvana you’ve been searching for.



SPECIFICATIONS

ANALOGUE IN/HEADPHONE OUT

  • Continuous output power into 8 Ohms
    and 4 Ohms
  • 50W (ref. 20 Hz-20 kHz at rated THD, both channels driven)
  • THD (20 Hz – 20 kHz)
  • <0.005 % at 1 V out
  • Signal-to-Noise Ratio
  • >100 dB (A-weighted, 32 ohms, ref. 2V out, unity gain)
  • Frequency response
  • ±0.3 dB (20 Hz – 20 kHz)
  • Output impedance
  • 11 ohms

ANALOG IN/SUBWOOFER OUT

  • THD (20 Hz – 20 kHz)
  • <0.005 % at 1 V out
  • Signal-to-Noise Ratio
  • >100 dB (A-weighted, 32 ohms, ref. 2V out, unity gain)
  • Frequency response
  • ±0.2 dB (20 Hz – 20 kHz)
  • Output impedance
  • 200 ohms

ANALOG IN/SPEAKER OUT

  • THD (20 Hz – 20 kHz)
  • <0.03 % (100 mW to 40 W, 8 ohms and 4 ohms)
  • Signal-to-Noise Ratio
  • >95 dB (A-weighted, 500 mV input, ref. 1 W out 8 ohms)
  • Frequency response
  • ±0.3 dB (20 Hz – 20 kHz)

PHONO IN/SPEAKER OUT

  • THD (20 Hz – 20 kHz)
  • <0.03 % (200 mW to 40 W, 8 ohms and 4 ohms)
  • Signal-to-Noise Ratio
  • >75 dB with IHF MM cartridge (A-weighted, ref. 5mV input 1 kHz and 1W output in 8 ohms)
  • Frequency response(RIAA deviation)
  • ±0.3 dB (20 Hz – 20 kHz)

Note:The RIAA response is consistent with a pre-emphasis that is rolled off at 50kHz by a second order filter, such as used in Neumann cutting lathes.

POWER CONSUMPTION

  • at ECO Standby mode
  • 0.5 Watts*
  • at Control Standby mode
  • 0.6 Watts**
  • OFF mode (Power switched OFF)
  • 0 Watts



* – After 20 minutes of no user interface interaction and no active source input
** – With established wireless Bluetooth connectivity and 20 minutes of no user interface interaction and no active source input

NOTE: Bluetooth connectivity is always live when configured.

DIMENSIONS & WEIGHT

  • Gross dimensions (W x H x D)
  • 435 x 70 x 285 mm (17 1/8 x 2 13/16 x 11 1/4″)
  • Net weight
  • 4.9 kg (10.8 lbs)
  • Shipping weight
  • 5.9 kg (13.0 lbs)
