NAD Hybird Digital Amplifier D3020 V2

Art and Sound

The original NAD 3020 introduced a generation of music lovers to true high-fidelity sound. In the 1970’s, over a million people rediscovered their music when they placed a NAD 3020 between their turntable and loudspeakers. This little gem outshined amplifiers costing 10 times more with its big, warm, detailed sound. Today, the source is more likely to be a computer or smartphone than a turntable, but the ability to choose speakers that perfectly suit one’s taste is still a compelling argument for upgrading to an NAD amplifier. The D 3020 starts with the original NAD 3020 concept and brings it straight into the 21st century using the latest high-speed digital technology. Now with V2, we have refined the looks and added a Phono input for vinyl playback.



SPECIFICATIONS

AUDIO SPECS

  • Rated Power at 8 ohms
  • 2 x 30 Watts
  • IHF Dynamic Power 8 ohms
  • 2 x 60 Watts
  • 4 ohms
  • 2 x 100 Watts
  • 2 ohms
  • 2 x 150 Watts
  • Signal/Noise Ratio (A-weighted, ref. 1 Watt)
  • ≥90dB
  • Channel Separation 1kHz
  • ≥75dB
  • 10kHz
  • ≥65dB
  • Channel Balance
  • 0 ±0.3dB
  • Frequency Response (20Hz – 20kHz)
  • 0dB to -0.3dB
  • Total Harmonic Distortion
  • ≤0.005%
  • Maximum input level
  • 5V
  • IMD (SMPTE)
  • 0.02%
  • IMD (CCIF)
  • 0.003%

MM PHONO INPUT

  • Phono Signal-to-Noise Ratio
  • >82 dB (200 ohms source, A-weighted, ref. 500 mV out)
    76 dB (MM cartridge source, IHF; A-weighted, ref. 500 mV out)
  • Input sensitivity
  • 1.15 mV (ref. 500 mV out, Volume maximum)
  • Maximum input signal at 1kHz
  • >90 mVrms (ref. 0.1 % THD)
  • Frequency response
  • ±0.3 dB (20 Hz – 20 kHz)

GENERAL

  • Standby Power
  • ≤0.5 Watts
  • Supports bit rate/sample rate
  • up to 24/192 (via Digital Audio input)
  • Unit Dimensions (W x H x D) Gross
  • 58 x 186 x 219mm
  • 2 5/16 x 7 3/8 x 8 5/8”
  • Net Weight
  • 1.38kg (3.05lb)
  • Shipping Weight
  • 2.1kg (4.6lb)
