Description
Five years since the introduction of ULTIMA, Chord Electronics’ most accomplished amplifier topology in its history, founder/owner John Franks has trickled the technology down into a full-width integrated amplifier for the first time, setting new performance standards for single-box amplification.
Inputs: 1x stereo balanced XLR inputs, 3x stereo unbalanced RCA
Outputs: 1x stereo XLR
1x stereo balanced XLR AV bypass input
1 x 12 V trigger output/input
Key Features
All-new design
Dual feed-forward error correction
AV bypass
Proprietary MOSFET
HF Switch mode power supply
Fully Balanced Circuitry
Included Top Light Ring
Solid Aluminium Chassis
Specifications
Frequency response
10 Hz-200 kHz +/- 3 dB
THD
0.01 % 20 Hz-20 kHz
Signal-to-noise ratio
90 dB on all inputs
Input impedance
100 kΩ
Input maximum voltage
3 V RMS
Output maximum voltage
35 V RMS
Gain
21dB
Channel separation
100 dB
Operation voltage
80-250 V AC auto-switching
Power output
125 W into 8Ω
Power consumption
200 W
Dimensions with included Integra legs:
13 cm(H) x 48 cm(W) x 38 cm(D)
Dimensions with optional side blocks (can not be stacked):
11 cm(H) x 43 cm(W) x 38 cm (D)
Weight:
14.75 kg
