Five years since the introduction of ULTIMA, Chord Electronics’ most accomplished amplifier topology in its history, founder/owner John Franks has trickled the technology down into a full-width integrated amplifier for the first time, setting new performance standards for single-box amplification.
Inputs: 1x Stereo Pair of Gold Plated Balanced XLR Inputs
1x Stereo Pair of Gold Plated Unbalanced RCA Inputs
1x 12v Trigger Input – Chord Electronics Auto Start
Output: 1x Pair of High Quality, High Current, Gold Plated Type Speaker Terminals
Key Features
All-new design
Dual feed-forward error correction
AV bypass
Proprietary MOSFET
HF Switch mode power supply
Fully Balanced Circuitry
Included Top Light Ring
Solid Aluminium Chassis
Specifications
Output Power:
300W RMS per channel into 8Ω
500W RMS per channel into 4Ω
Power consumption:
Full power – 2000 W
Standby – 10 W
THD:
0.005%
Frequency Response:
-1dB – 0.5Hz – 100kHz
Gain:
30dB
Dimensions with included Integra Legs:
18cm (H) x 48cm (W) x 36cm (D)
Dimensions with optional Side Blocks:
15cm (H) x 42cm (W) x 36cm (D)
Weight:
22.4kG
