The Audiolab 9000Q is a preamplifier that embodies the audio excellence of the flagship 9000 series. This refined preamplifier embodies a symphony of innovation and craftsmanship, featuring functional enhancements that elevate your listening journey. With its tone controls and fully balanced signal paths, the 9000Q empowers you to explore your music with unparalleled versatility and precision.
| General Description |
Preamplifier |
| Design Philosophy and Core Technology |
ES9038Pro 32-bit DAC
MQA Full decoder (PC USB, Coax/Optical)
4.3” 800 x 480 IPS LCD
Bluetooth 5.1 (aptX/aptX HD/LDAC) streaming
Dedicated Current-Feedback Headphone Amp
Dedicated High Performance Low Noise MM Phono stage |
| Inputs |
3 x Analogue, 1 x XLR, 1 x Phono (MM)
2 x SPDIF (Coax), 2 x SPDIF (Optical)
1 x PC USB (USB B), 1 x Bluetooth (aptX/aptX HD/LDAC) |
| Outputs |
2 x RCA, 1 x XLR, 1 x Headphone, 2 x 12V Trigger |
| Sampling Frequency |
Optical/Coaxial: 44.1-192kHz
Sampling Frequency
PC USB: 44.1kHz-768kHz (PCM) / DSD64, DSD128, DSD256, DSD5, DSD512 |
| Preamp / DAC |
|
| D to A Converter |
ES9038Pro |
| Input Sensitivity |
1Vrms (Line, Volume = 0dB)
2Vrms (XLR, Volume = 0dB)
4.5mV (Phono MM, Volume = 0dB) |
| Total Harmonic Distortion (THD) |
< 0.001% (1KHz @ 0dBFS) |
| Frequency Response |
20Hz - 20kHz (+/-0.1dB) |
| Output lmpedance |
120 ohm |
| Max.Sampling Frequency |
Optical, Coaxial: 192KHz
PC USB: PCM768kHz, DSD512 |
| Signal-to-noise Ratio (S/N) |
> 113dB (A-weighted, RCA)
> 117dB (A-weighted, XLR Direct) |
| Headphone Amplifier |
|
| Total Harmonic Distortion (THD) |
< 0.01% (1kHz, 50mW ) |
| Output lmpedance |
2.35 ohm |
| Load lmpedance |
20-600 ohm |
| General |
|
| Standby Power Consumption |
<0.5W |
| Net Weight |
6.2kg |
| Gross Weight |
8kg |
| Dimensions(mm) (W x H x D) |
444 x 90 x 328 mm |
| Carton Size (mm) (W x H x D) |
514 x 165 x 470 mm |
| Finish |
Silver / Black |
| Power Requirements(depending on region) |
220-240V - 50/60Hz
100-120V - 50/60Hz |
| Standard Accessories |
Power Cord, Remote Control, User Manual, Antennas |
